insulated CONNECTOR HOUSING RED to be crimped to connect an electrical cable on a Super B Li-ion Battery
-
This power connector is the premium choice for your battery. The high temperature rating (125°C/257°F) giving it a certified Flammability Rating and its chemical resistance makes this connector perfect for use in engine compartments of your microlight aircraft, airplane, motorcycle, jet ski, snowmobile or quad.
-
Technical specifications
- HOUSING, Black, 50A TO 75A
- Series : Modular Power
- Colour : Red
- Connector Type : Rectangular
- Current Rating : 50A
- Flammability Rating : UL94V-0
- Material : Polycarbonate
- Max Operating Temperature : +125°C
- Min Temperature Operating : -20°C
- Mounting Type : Cable
- No. of Ways : 1
- Termination Method : Crimp
- Max Current : 75A
- Height : 17mm
- Width : 17mm
- Length : 48mm
REMEMBER :
The use of a special smart charger for LiFePO4 batteries is MANDATORY.
Thus will be taken into account the ambient temperature, the size of the battery, the potential differences of the elements of the battery. Recovery functions, optimization (balancing), tests of absorption and retention after charging.
